Description
- Diameter of rope = 2mm
- Number of strands = 7
- Number of wires per strand = 7
- Lay = RHOL
- Finish = Galvanised or Grade 316 Stainless
Minimum Breaking Load, Factor of Safety & Safe Working Load
Galvanised Steel: 260kg MBL, 5:1 FOS = SWL 50Kg
Stainless Steel: 242Kg MBL, 5:1 FOS = SWL 48Kg
Cutting Method
Side cutters to give a clean, crush-free cut, to allow wire rope to feed through ferrules or wire rope grips cleanly, use either (NT119) or (NT120)
Retention Method
Galvanised Steel Wire Rope: Use 2.5mm Aluminium Ferrules (NF280) or Galvanised Steel Wire Rope Grips (NF140)
Stainless Steel Wire Rope: Use 2.5mm Copper Ferrules (NF139) or Stainless Steel Wire Rope Grips (NF229)
